Deye SUN-100K-G03 100kW String Inverter

The Deye SUN-100K-G03 is a high-efficiency 100kW three-phase string inverter developed for commercial and industrial photovoltaic systems, factory rooftop solar plants, warehouse solar projects, carport PV systems, and ground-mounted solar power stations. With up to 150kW PV input power, 6 MPPT trackers, and 98.8% maximum efficiency, this grid-tied solar inverter is engineered to maximize yield while simplifying large-scale string design and O&M.

Inquiry Us Add to cart

Previous: Deye SUN-12K-SG05LP3-EU-SM2 12kW Low Voltage Three Phase Hybrid Inverter

Next: Deye SUN-125K-G01P3-EU-AM8 125kW String Inverter

More details

Its wide MPPT voltage range, high string current capability, and optional string intelligent monitoring make it a strong choice for EPC contractors, solar distributors, and commercial PV developers who need dependable performance and easy troubleshooting. Zero-export control, VSG support, Type II surge protection, and optional anti-PID functionality improve grid compatibility and long-term reliability in demanding outdoor environments.

This model is suitable for search keywords such as 100kW string inverter, three phase on-grid inverter, commercial solar inverter, C&I photovoltaic inverter, industrial solar inverter, 100kW grid tied inverter, high efficiency PV inverter, rooftop solar inverter, utility grade string inverter, and 6 MPPT solar inverter. Official page: https://www.deyeinverter.com/product/three-phase-string-inverter/sun70-75-80-90-100-110kg03-70110kw-three-phase-6-mppt.html

Technical Specifications Feedback

Item	Details
Rated AC output active power	100 kW; max AC apparent power: 110 kVA
Three-phase grid output	220/380 V, 230/400 V; grid connection 3L+N+PE; rated frequency 50/60 Hz
PV side	Max PV input power 150 kW; max PV input voltage 1,000 V
Start-up voltage	250 V
MPPT voltage range	200–850 V; rated PV input voltage: 600 V
MPPT / strings	6 MPPT; 6/4+4+4+4+4+4 strings
Max operating PV input current	40+40+40+40+40+40 A
Max input short-circuit current	60+60+60+60+60+60 A
Rated AC output current	151.5/144.9 A
Max AC output current	166.7/159.4 A
Power factor adjustment range	0.8 leading to 0.8 lagging; THDi <3%
Efficiency	Max 98.8%; Euro efficiency 98.2%; MPPT efficiency >99%
Protection / features	Type II DC/AC SPD, zero export application, VSG application, optional string intelligent monitoring, optional anti-PID, IP65, operating temperature -25°C to +60°C, max altitude 4000 m
